Supply voltage	10 V DC ... 30 V DC
Ripple	≤ 10 Vpp 1)
Voltage drop	≤ 2 V
Current consumption	20 mA 2)
Time delay before availability	≤ 50 ms
Hysteresis	3 % ... 15 % 3)
Reproducibility	≤ 2 %
Temperature drift (of Sr)	± 10 %
Continuous current Ia	≤ 200 mA
Cable gland clamping area	M20 1.5
Wire size	≤ 2.5 mm²
Short-circuit protection	✔
Reverse polarity protection	✔
Power-up pulse protection	✔
Shock and vibration resistance	30 g, 11 ms / 10 ... 55 Hz, 1 mm
Ambient operating temperature	–25 °C ... +85 °C
Ambient storage temperature	–40 °C ... +85 °C
Housing material	Plastic, PA 66
Sensing face material	Plastic, PA 66
Tightening torque, max.	1.8 Nm
Protection class	II 4)
UL File No.	E348498

"SICK" Inductive proximity sensors IQ40-20BPSKK0S Number 1071843
